NEW BorgWarner S200G062 Turbo CAT Earth Moving Loader 3126 7.0L 178478 173106
BRAND NEW GENUINE BORGWARNER TURBOCHARGER
This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
NOTE: This turbocharger has an aftermarket compressor housing. Everything else are genuine BorgWarner parts.
Fits the following:
Part Number: 173106
Interchangeable Number: 167865, 167865R, 171173, 171173R, 171174, 171174R, 171963, 173106R, 173107, 173107R, 178478, 178478R, 473106
OEM Number: 0R-6973, 0R6973, 0R-9802, 0R9802, 10R-0364, 10R0364, 120-8362, 1208362, 177-1063, 1771063, 177-1064, 1771064, 195-6029, 1956029, 198-1845, 1981845, 198-1846, 1981846
Serial Number: 55K7976-UP, 6JK10689-UP, 6JK8177-8177, 6JK8180-8180, 6JK8182-8182, 6JK8193-UP,
Turbo Model: S200G062
Manufacturer: BorgWarner - 3K - Schwitzer, BWTS USA
Year: 2001-10
Engine: 3126
Displacement: 7.0L, 7000 ccm
Fuel: Diesel
Power: 165 kW/221 HP
Speed: 2200 RPM
Angle α (Compressor Housing): 310°
Angle β (Turbine Housing): 255°
Actuator: 171160 (2061016230)
Back Plate: 167744 (1800016020, 1253200300, 304200001)
Bearing Housing: 173112 (173111)(Oil Cooled)(1900011197)
CHRA: 173110 (173110R, 2063097, 178199, 473110, 478199)(1000070073)
Compressor Wheel: 173109 (173108)(Ind. 81.4 mm, Exd. 56 mm, 7+7 Blades)(1200016470)
Gasket (Oil Outlet): 210021 (409037-0000, 210021-0000, 311496, 413671-0000, 3519807)
Gasket (Turbine Inlet): 409039-0000 (210022-0000)
Gasket (Turbine Outlet): 210245 (Inox Steel)
Gasket Kit: 318420 (318419)(2090010076)
Heat Shield: 167745 (167997)(2030016117, 306010011)
Repair Kit: 318382 (318383, 315565)(1253200750, 5000030021, 309200001)
Turbine Wheel: 167729 (Ind. 69.59 mm, Exd. 60.63 mm, 10 Blades)(1100016453, 301050005)
NOTE: Recirculation groove in compressor housing.
Application:
2001-10 Caterpillar 938G, 950G, 962G Wheel Loader with 3126 Engine
2001-10 Caterpillar Earth Moving with 3126 Engine
Caterpillar 525B, 535B Skidder
Caterpillar IT38G, IT62G Integrated Tool Carrier
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
NOTE: This turbocharger has an aftermarket compressor housing. Everything else are genuine BorgWarner parts.
Fits the following:
Part Number: 173106
Interchangeable Number: 167865, 167865R, 171173, 171173R, 171174, 171174R, 171963, 173106R, 173107, 173107R, 178478, 178478R, 473106
OEM Number: 0R-6973, 0R6973, 0R-9802, 0R9802, 10R-0364, 10R0364, 120-8362, 1208362, 177-1063, 1771063, 177-1064, 1771064, 195-6029, 1956029, 198-1845, 1981845, 198-1846, 1981846
Serial Number: 55K7976-UP, 6JK10689-UP, 6JK8177-8177, 6JK8180-8180, 6JK8182-8182, 6JK8193-UP,
Turbo Model: S200G062
Manufacturer: BorgWarner - 3K - Schwitzer, BWTS USA
Year: 2001-10
Engine: 3126
Displacement: 7.0L, 7000 ccm
Fuel: Diesel
Power: 165 kW/221 HP
Speed: 2200 RPM
Angle α (Compressor Housing): 310°
Angle β (Turbine Housing): 255°
Actuator: 171160 (2061016230)
Back Plate: 167744 (1800016020, 1253200300, 304200001)
Bearing Housing: 173112 (173111)(Oil Cooled)(1900011197)
CHRA: 173110 (173110R, 2063097, 178199, 473110, 478199)(1000070073)
Compressor Wheel: 173109 (173108)(Ind. 81.4 mm, Exd. 56 mm, 7+7 Blades)(1200016470)
Gasket (Oil Outlet): 210021 (409037-0000, 210021-0000, 311496, 413671-0000, 3519807)
Gasket (Turbine Inlet): 409039-0000 (210022-0000)
Gasket (Turbine Outlet): 210245 (Inox Steel)
Gasket Kit: 318420 (318419)(2090010076)
Heat Shield: 167745 (167997)(2030016117, 306010011)
Repair Kit: 318382 (318383, 315565)(1253200750, 5000030021, 309200001)
Turbine Wheel: 167729 (Ind. 69.59 mm, Exd. 60.63 mm, 10 Blades)(1100016453, 301050005)
NOTE: Recirculation groove in compressor housing.
Application:
2001-10 Caterpillar 938G, 950G, 962G Wheel Loader with 3126 Engine
2001-10 Caterpillar Earth Moving with 3126 Engine
Caterpillar 525B, 535B Skidder
Caterpillar IT38G, IT62G Integrated Tool Carrier
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
$1,595.00
